Copper C110
Material type: Metal
Copper C110, being a tough pitch copper alloy, is not easily welded or brazed because it suffers from embrittlelment when heated in a reducing atmosphere. This occurs because hydrogen reacts with the oxide in the metal to form steam and causes cracking.
Process compatibility
Material Color
Copper
Material advantages
Copper C110 can be soldered with good results. It has excellent hot and cold forming characteristics.
Material shortcomings
Copper C110 has a poor machinability rating of 20%.
Recommended description
Due to its Conductivity, corrosion resistance, and ductility this material has a wide range of applications.
Properties
Name | |
---|---|
Tensile strength | 230 MPa |
Yield strength | 140 MPa |
Modulus of elasticity | 120 GPa |
Elongation at break | 15 - 50 % |
Hardness | 40 HRF |
Thermal expansion coefficent | 17 - 17.7 10^-6 ºC |
Thermal conductivity | 380 - 388 W/(m⋅°C) |
Electrical resistivity | 1.71 - 1.76 μΩ*cm |
Common applications
• Architectural
Building fronts, downspouts, flashing, gutters, roofing, screening, spouting
• Automotive
Gaskets, radiators
• Electrical instruments
• Vacuum capacitors
