PPS-CF

Material type: Plastic

PPS-CF is a carbon fiber reinforced polyphenylene sulfide composite. Thanks to the properties of polyphenylene sulfide (PPS) resin itself and the reinforcing effect of carbon fiber, PPS-CF has excellent solvent resistance, corrosion resistance, heat resistance, flame retardancy, strength, stiffness, dimensional stability, etc., and is a special engineering plastic that can meet the application needs of engineering plastics in reflushing.

Process compatibility

FDM

Material Color

Black

Material advantages

Ultra-high temperature resistance and mechanical properties; It has UL94 V-0 flame retardant performance; Solvent and chemical resistance, second only to PTFE (Teflon) in performance.

Material shortcomings

The surface coating and coloring are more difficult, the impact toughness and elongation at break are low, and the price is higher.

Recommended description

PPS-CF retains PPS's superior solvent and chemical resistance, making it highly resistant to acids, alkalis, and salts under conventional conditions. It also has a saturated water absorption rate as low as 0.05%, ensuring that its mechanical and thermal properties are not affected by moisture. And maintain its performance and durability, making it ideal for use in wet environments.

Properties

Name
Density	1.26 g/cm³
Melting Temperature	284°C
Tensile Strength (x-direction)	87 MPa
Tensile Strength (z-direction)	24 MPa
Bending Strength (x-direction)	142 MPa
Bending Strength (z-direction)	36 MPa
Bending Modulus (x-direction)	7160 MPa
Bending Modulus (z-direction)	2460 MPa
Modulus of elasticity (x-direction)	8230 MPa
Modulus of elasticity (z-direction)	2850 MPa
Impact Strength (x-direction)	27.8 kJ/m²
Impact Strength (z-direction)	2.8 kJ/m²
