TPU(FDM)

Material type: Flexible, Good impact resistance, Durable

TPU is called thermoplastic polyurethane elastomer rubber. It is a type of polymer material between rubber and plastic. It is mainly divided into polyester type and polyether type. It is a mature environmentally friendly material. TPU(FDM) 95A HF is a flexible and highly tough consumable material with excellent impact resistance. It is suitable for printing various parts that need to withstand impact, drop, and collision.

Process compatibility

FDM

Material Color

White

Black

Red

Yellow

Blue

Gray

Green

Material advantages

Finished product: Flexible, good abrasion resistance, good grease resistance, high strength, translucent.

Material shortcomings

Finished product: difficult to post-production, difficult to glue parts, less changes than some other plastic materials.

Recommended description

TPU has the characteristics of high resilience, good tensile resistance, good flexibility, strong fracture strain ability, good abrasion resistance and strong environmental resistance. It is a mature environmentally friendly material.

Properties

Name
Shore Hardness A	95A
Flexural Modulus 20°C	27MPa
Flexural Modulus 60°C	72MPa
Tensile Strength (x-direction)	27Mpa
Tensile Strength (z-direction)	22Mpa
Elongation (x-direction)	650%
Elongation (z-direction)	480%
Poisson ratio (Hencky)	0.45
Density	1.3g/cm3
Melting temperature	180℃
